1Model No.DC55JB-12240PWMDC55JB-12240VRDC55JB-12240SDC55JB-24320PWMDC55JB-24320VRDC55JB-24320SPWM:PWM speed regulation (50-800HZ/ 5V) VR:0~5V/potentiometer speed regulation S:fixed speed,no speed chan

  • Model : DC55JB
  • Rated Voltage : DC12V 24V
  • Max Static Head : 32M
  • Max Flow rate : 2000L/H
  • Input Power : 150W(160W)
  • Inlet Outer Diameter : 20mm
  • Outlet Outer Diameter : 20mm
  • Size : 162mm*77mm*112mm
  • Weight : 1.2kg
  • Material : PPS+20%FG(optional)
  • Waterproof : IP68
  • Noise : Less than 35dB
  • Liquid Temperature : 0-100°C

1

Model No.

DC55JB-12240PWM

DC55JB-12240VR

DC55JB-12240S

DC55JB-24320PWM

DC55JB-24320VR

DC55JB-24320S

PWM:PWM speed regulation

(50-800HZ/ 5V)

VR:0~5V/potentiometer

speed regulation

S:fixed speed,no speed change


2

Rated Voltage

12V DC

24V DC



3

Working Voltage

5-12V

14-30V

Within this range, the

pump can work normally.


4

Rated Current

8.3A(9.2A)

6.3A(6.7A)

Closed outlet current

(open pumping current)


5

Input power

100W(110W)

150W(160W)

Closed outlet power

(open pumping power)


6

Max. Flow rate

1800L/H

2000L/H

Flow rate without

lifting

height(horizontal flow

rate)


7

Max. head

24M

32M

Static head


8

Mini input power supply

12V-10A

24V-7A
